Parameters of medium rate Ni-Cd cells
| 型 號 | 額定電壓V | 額定容量Ah | 參考尺寸mm | 極柱螺紋 |
Kg |
L | 國外型號 | ||
| 長 | 寬 | 高 | |||||||
| GNZ30 | 1.2 | 30 | 134 | 52 | 257 | M10 | 2.30 | 0.83 | KPM30 |
| GNZ40 | 1.2 | 40 | 141 | 71 | 295 | M10 | 4.0 | 1.0 | KPM40 |
| GNZ50 | 1.2 | 50 | 139 | 79 | 291 | M16 | 5.00 | 1.30 | KPM50 |
| GNZ60 | 1.2 | 60 | 139 | 79 | 291 | M16 | 5.00 | 1.20 | KPM60 |
| GNZ75 | 1.2 | 75 | 139 | 79 | 362 | M16 | 6.50 | 2.00 | KPM75 |
| GNZ80 | 1.2 | 80 | 139 | 79 | 362 | M16 | 7.50 | 2.00 | KPM80 |
| GNZ100 | 1.2 | 100 | 164 | 104 | 345 | M20 | 9.30 | 1.75 | KPM100 |
| GNZ120 | 1.2 | 120 | 164 | 104 | 345 | M20 | 11.00 | 2.40 | KPM120 |
| GNZ120-(4) | 1.2 | 120 | 139 | 89 | 362 | M16 | 7.30 | 1.90 | KPM120 |
| GNZ150 | 1.2 | 150 | 167 | 162 | 345 | M20 | 12.50 | 2.70 | KPM150 |
| GNZ200 | 1.2 | 200 | 167 | 162 | 345 | M20 | 13.50 | 2.70 | KPM200 |
| GNZ250 | 1.2 | 250 | 282 | 170 | 348 | M20 | 22.00 | 5.00 | KPM250 |
| GNZ300 | 1.2 | 300 | 282 | 170 | 348 | M20 | 24.00 | 6.00 | KPM300 |
| GNZ300-(2) | 1.2 | 300 | 176 | 161 | 540 | M20 | 22.6 | 5.00 | KPM300 |
| GNZ500 | 1.2 | 500 | 285 | 172 | 490 | M20 | 36.5 | 8.50 | KPM500 |
| GNZ600 | 1.2 | 600 | 285 | 172 | 490 | M20 | 45.00 | 9.70 | KPM600 |
| GNZ700 | 1.2 | 700 | 395 | 185 | 560 | M20 | 55.00 | 11.00 | KPM700 |
| GNZ800 | 1.2 | 800 | 395 | 185 | 560 | M20 | 64.00 | 15.00 | KPM800 |
| GNZ1000 | 1.2 | 1000 | 395 | 185 | 560 | M20 | 66.00 | 14.00 | KPM1000 |
| GNZ1200 | 1.2 | 1200 | 395 | 185 | 560 | M20 | 68.00 | 12.00 | KPM1200 |
